IRON-50 EX DC

Robust ATEX Fuel Transfer Pump

Codes

   12Vdc: 10063

   24Vdc: 10153

• Vane: Eccentric self-adjusting blades

• Free Flow rate up to 50 l/min

• Delivery head up to 20m

• Self priming pipe Ø 1" or greater ;

  • Vertical up to 2.7m

  • Suction pipe length up to 5m

• Internal recycle valve

• Motor: 180W - IP55

• Duty Cycle: S2 30 minutes

• With thermal motor protection

• No internal electronics that can fail

• Classified: ATEX II 2G

  • Motor:  Ex db IIA T4 Gb

  • Pump:  Ex   h IIB T4 Gb

• F 1" G Threaded connection

• Internal 350 micron strainer

• Anti-rust treatment

• 2m Cable

• Weight 12 kg

• Suitable for: Petrol and Diesel, AVGAS 100 / 100LL,  JET A / A1  and Paraffin
